Equipment

19-inch Spectrally Controlled Backlit Control Panel


Features:

  • Provides operator interface to control, monitor, and manage devices on the Advanced Communication and Control System network
  • Spectrally Controlled Backlit Control Panel technology is patented
  • Extreme Rugged Display Panel Design is patented
  • Designed to meet Grade A, Class I MIL-STD-901D hardmounted
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300 Power Quality with Spike Voltage
  • -25°C to +65°C Operating Temperature
  • UPS Battery Back-up for 15 minutes
  • 10/100/1000 Base-TX Ethernet Port
  • Windows 7/10 Operating Systems
  • 16 Gbyte Solid State Drive storage
  • Atom 1.33 GHz Dual Core Central Processor Unit
  • Weight: 70 pounds

Part Number: AY-0601-022





12-inch Spectrally Controlled Backlit Control Panel


Features:

  • Provides operator interface to control, monitor, and manage devices on the Advanced Communication and Control System network
  • Spectrally Controlled Backlit Control Panel Technology is patented
  • Extreme Rugged Display Panel Design is patented
  • Grade A, Class I MIL-STD-901D hardmounted
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300 Power Quality with Spike Voltage
  • -25°C to +65°C Operating Temperature
  • UPS Battery Back-up for 15 minutes
  • 10/100/1000 Base-TX Ethernet Port
  • Windows 7/10 Operating Systems
  • 16 Gbyte Solid State Drive storage
  • Atom 1.33 GHz Dual Core Central Processor Unit
  • Weight: 40 pounds

Part Number: AY-0601-032 NAVAIR P/N: 4010AS1100





Network Switch Type 1 and Type 2

Features:

  • Provides Ethernet 10/100/1000 Base-TX Copper Ports
  • Provides Ethernet 100/1000 Fiber Optic Ports with Redundant Ring
  • Designed to meet Grade A, Class I MIL-STD-901D hardmounted
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300 Power Quality with Spike Voltage
  • -25°C to +65°C Operating Temperature
  • Provides 6 Copper Ethernet and/or 6 Fiber Optic ports
  • UPS Battery Back-up for 15 minutes
  • Weight: 26 pounds

Part Number: AY-0601-015TY1, NAVAIR P/N: 4010AS2100-1 & AY-0601-030TY2





Modular Protocol Controller

Features:

  • Provides interface management and protocol conversion for Ethernet to IEEE RS 485, IEEE RS 232 and GP I/O networks
  • Provides Fault Tolerant IEEE RS 485 Wrap around communication technology (Patented)
  • Designed to meet Grade A, Class I MIL-STD-901D hardmounted
  • MIL-STD-167-1 Vibration
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300A Power Quality with Spike Voltage
  • -25°C to +65°C Operating Temperature
  • Weight: 16 pounds
Part Number: AY-0601-023, NAVAIR P/N: 4010AS3100-1





Variable Transformer Power Control Module - 15 amp


Features:

  • Provides Pure Sine Wave variable voltage output for analog linear variable power output levels
  • Available in 15A & 30A modules with voltage output accuracy
  • Designed to meet Grade A, Class I MIL-STD-901D hardmounted
  • Designed to meet MIL-STD-167-1 Vibration
  • Designed to meet MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • Designed to meet MIL-STD-1399 DC Mag Field and -300A Power Quality with Spike Voltage
  • Designed to meet -25°C to +65°C Operating Temperature
  • Weight: 130 pounds

Part Number: AY-1001-008, NAVAIR P/N: 4010AS4100-1





LED Flexible Driver Module (LFDM)


Features:

  • Provides power output to drive LED Lighting
  • Connects to the ALS-CPS or ACCS network via a RS-485 interface
  • Provides drivers for 48 independent LED lights or strings of lights
  • Housed in an aluminum enclosure which is designed to be bulkhead mounted. The exterior is powder coated with a chem-film coated interior
  • Grade A, Class I MIL-STD-901D hardmounted
  • MIL-STD-167-1 Vibration
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300A Power Quality with Spike Voltage
  • -25°C to +65°C Operating Temperature
  • Weight: 150 pounds

Part Number: AY-0601-028, NAVAIR P/N: 3975AS9100-1





Telerobotic Firefighting Nozzle Control Panel


Features:

  • Provides touch screen and joystick operator interface to control, monitor, and manage Telerobotic Firefighting Nozzles
  • Designed to meet Grade A, Class I MIL-STD-901D hardmounted
  • MIL-STD-167-1 Vibration
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300A Power Quality with Spike Voltage
  • -25°C to +65°C Operating Temperature

Part Number: AY-0601-027





Battery Monitoring System


Features:

  • Provides operator touch screen interface to control, monitor, and manage large battery monitoring systems
  • Three Strings: 126 Cells/String: 2 Mega Watts Emergency Battery Power
  • System includes 1 Supervisory Computer and Remote Control Panels with multiple Data Acquisition Modules (DAM)
  • 48 Temperature Sensors/String
  • The software operates on the Microsoft XP Embedded Operating System

Part Number: AY-02400-003





Personnel Safety Barrier Local Control Switch


Features:

  • Provides local request to the Helo-Control Officer to open the Personnel Safety Barrier
  • Provides status of the request to the local operator
  • Designed to meet MIL-STD-167-1 Vibration
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300A Power Quality with Spike Voltage
  • Designed to meet -25°C to +65°C Operating Temperature

Part Number: AY-0601-024





Synchro Signal Indicators

Features:

  • Provides synchro-based repeater technology driven by either a master synchro or solid state sychro drivers
  • Can be driven by 60 Hz or 400 Hz power source
  • Illuminated and Non-Illuminated Wind Direction or Wind Speed indicators
  • Rudder Angle, Z-Drive Indicator, Ship's Course Indicators
  • Analog Dial
Part Number: AY-04400-001-1 and AY-04400-001-2





Actuator Control Box

Features:

  • Provides reversing motor control of 1.5 Amp, 3 phase, 440 VAC motor with position feedback sensor control and On/Off control
  • Provides a safety sensor circuit with intrinsic failsafe mode
  • Incorporates Temperature Sensors
  • Grade A, Class I MIL-STD-901D
  • MIL-STD-167-1 Vibration
  • MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • MIL-STD-1399 DC Mag Field and -300A Power Quality with Spike Voltage
Part Number: AY-0601-025





Deck Status Panel

Features:

  • Provides operator input control for Flight Deck Status indicators: Clear, Caution, Foul and Wave-Off
  • Operates on Ethernet port
  • Incorporates local dimming for status indicators
Part Number: AY-0601-029





Door Interlock Switch

Features:

  • Operates with the Local Light Control Switch to change lighting circuits from white to red
Part Number: AY-0601-018





Local Light Control Switch

Features:

  • Provides local control and / or network control of up to four (4) independent 115VAC circuits
  • Each circuit provides ON / OFF control and red / white light selection
  • Incorporates two (2) door interlock inputs
  • Operates on IEEE RS-485 communication networks
  • Designed to meet MIL-STD-167-1 Vibration
  • Designed to meet MIL-STD-461, 464, EMI, EMP, Lightning Strike
  • Designed to meet MIL-STD-1399 DC Mag Field and -300A Power Quality with Spike Voltage
  • Designed to meet -25°C to +65°C Operating Temperature
Part Number: AY-0601-006
